C37 LED Candle E27 | Candle

HX-S5F-C37, HX-S6F-C37, HX-S7F-C37

To print

Basic information:
Plastic Aluminium C37 5W 6W 7W E27 LED candle bulb
Base: E14, E27, B22
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PBT+Aluiminium shell, PC diffuser
Application: Home, Desk, Shops, restaurants, hotels, coffee bar,etc.

top mid pic.png

TECHNICAL CHARACTERISTICS

Safety  according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015



CodeInputPower PF Lumen C.R.IC.C.T.BaseDim or Non-dim
C37 LED Candle 5W
HX-S5F-C37100-240V5 W0.5400lm803000KE27/B22Option
HX-S5F-C37100-240V5 W0.5400lm804000KE27/B22Option
HX-S5F-C37100-240V5 W0.5400lm806500KE27/B22Option
HX-S5F-C37100-240V5 W0.5400lm808000KE27/B22Option
CodeInputPower PF Lumen C.R.IC.C.T.BaseDim or Non-dim
C37 LED Candle 6W
HX-S6F-C37100-240V6 W0.5480lm803000KE27/B22Option
HX-S6F-C37100-240V6 W0.5480lm804000KE27/B22Option
HX-S6F-C37100-240V6 W0.5480lm806500KE27/B22Option
HX-S6F-C37100-240V6 W0.5480lm808000KE27/B22Option
CodeInputPower PF Lumen C.R.IC.C.T.BaseDim or Non-dim
C37 LED Candle 7W
HX-S7F-C37100-240V7 W0.5560lm803000KE27/B22Option
HX-S7F-C37100-240V7 W0.5560lm804000KE27/B22Option
HX-S7F-C37100-240V7 W0.5560lm806500KE27/B22Option
HX-S7F-C37100-240V7 W0.5560lm808000KE27/B22Option
