Globe mini 3-6W E14 | Golf

HX-SxF-G45

To print

Basic information:
Plastic Aluminium globe mini E14 LED lamp
Base: E14, E27, B22
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PBT+Aluiminium shell, PC diffuser
Application: Home, Desk, Shops, restaurants, hotels, coffee bar,etc.

G45 reflector top

TECHNICAL CHARACTERISTICS

Safety  according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015



CodeInputPower DF Lumen C.R.IC.C.T.BaseDimmable
Globe Mini E14 3W LED lamp
HX-S3F-G45220-240V3 W0.4255803000KE14Option
HX-S3F-G45220-240V3 W0.4255804000KE14Option
HX-S3F-G45220-240V3 W0.4255805000KE14Option
CodeInputPower DF Lumen C.R.IC.C.T.BaseDimmable
Globe Mini E14 4W LED lamp
HX-S4F-G45220-240V4 W0.4340803000KE14Option
HX-S4F-G45220-240V4 W0.4340804000KE14Option
HX-S4F-G45220-240V4 W0.4340806000KE14Option
CodeInputPower DF Lumen C.R.IC.C.T.BaseDimmable
Globe Mini E14 5W LED lamp
HX-S5F-G45220-240V5 W0.5425803000KE14Option
HX-S5F-G45220-240V5 W0.5425804000KE14Option
HX-S5F-G45220-240V5 W0.5425806000KE14Option
CodeInputPower DF Lumen C.R.IC.C.T.BaseDimmable
Globe Mini E14 6W LED lamp
HX-S6F-G45220-240V6 W0.5510803000KE14Option
HX-S6F-G45220-240V6 W0.5510803000KE14Option
HX-S6F-G45220-240V6 W0.5510803000KE14Option
