R63 LED lamp | Reflector

HX-S8F-R63

Basic information:
Plastic Aluminium R63 LED lamp
Base: E27/B22
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PBT+Aluiminium shell, PC diffuser
Application: Home, Desk lamp, Shops, restaurants, hotels, coffee bar,etc.

top mid pic R63.png

TECHNICAL CHARACTERISTICS

Safety according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015

R63 reflector middle content

Code	Input	Power	DF	Lumen	C.R.I	C.C.T.	Base	Dimmable
R63 REFLECTIVE LED LAMP
HX-S8F-R63	220-240V	8 W	0.5	680lm	80	3000K	E27	Option
HX-S8F-R63	220-240V	8 W	0.5	680lm	80	4000K	E27	Option
HX-S8F-R63	220-240V	8 W	0.5	680lm	80	6500K	E27	Option
HX-S8F-R63	220-240V	8 W	0.5	680lm	80	8000K	E27	Option
