LED T8 9W 14W 18W Nano | T8

T80609NA,T80914NA,T81218NA

To print

BASIC INFORMATION:
Nano LED Tube T8 0.6m, 1.2m, 1.5m 9-39W
Base: G13 white end caps
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: Nano plastic, PC Cap
Application: Supermarkets, office, Shops, restaurants, hotels,etc.

top mid pic nano.png

TECHNICAL CHARACTERISTICS

Safety  according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015


mid pic.png

Code Power PF Lumen Color Size
LED NANO PLASTIC T8 TUBE - 9W
T80609NA9 W0.6900lm3000K26*588mm
T80609NA9 W0.6900lm3000K26*588mm
T80609NA9 W0.6900lm3000K26*588mm
Code Power PF Lumen Color Size
LED NANO PLASTIC T8 TUBE - 18W
T81218NA18 W0.61800lm3000K26*1198mm
T81218NA18 W0.61800lm4000K26*1198mm
T81218NA18 W0.61800lm6500K26*1198mm
